Carlo Gavazzi Soft Starter RSBS2332A2V22C24HP Soft starting of 1-Phase scroll compressors

This motor controller, intended to be used with single-phase scroll compressors can limit inrush currents to 40AACrms for RSBS2325A2V.2C24.. and 45AACrms for RSBS2332A2V.2C24..1. Upon applying the control signal, soft starting is achieved within a 600ms interval2. At the end of the soft-start function, the semiconductors are bypassed by electromechanical relays. The device rating is based on a maximum of 12 starts per hr.3��

Application of supply voltage is indicated by a green LED in the full ON state. Alarm indication is provided through a red LED which signals the type of alarm via a user friendly flashing sequence.

Delay between starts and/or from stop to start is indicated via an orange LED.

Short circuit and Overload protection are not provided with this controller and must be procured separately. Starting and running capacitors are required for controller to operate as intended. The RSBS can also be supplied with an optional auxiliary alarm relay (Option - V22).
